1:3 millon 1/2.8-inch CMOS 3M pixels;
2:Full HD 2304 * 1296 resolution;
3:High definition dedicated lens 4mm fixed;
4:IR-CUT automatic switching, achieving day and night monitoring;
5:2 850mm infrared lamps and 21 white light lamps, infrared distance: 8-10M;
6:Supports digital wide dynamic and 3D noise reduction functions;
7:H. 265 video compression technology, high image quality, low bit rate;
8:Support remote monitoring on mobile phones (iOS, Android);
9:Supporting cloud services;
10:Support third-party value-added services, optional (Alexa, Google)
11;Supports bidirectional voice calls
12:Support for mobile detection and recording
参数 | 规格 | |
---|---|---|
CPU方案 | 规格 | TC31 |
传感器成像单元 | 型号 | SC3335 |
CMOS尺寸 | 1/2.8-inchCMOS2Mpixels | |
有效像素 | 3MP | |
传感器成像单元 | 型号 | LK64-W130 |
焦距 | 4mm | |
相对抒径(光圈) | F2.0 | |
接口类型 | M12*0.5 | |
FOV(视场角) | 100.3 | |
分辨率 | 2304*1296 | |
镜片层数 | 1G3P | |
夜视 | 夜视距离 | 8-10m |
感光方式 | 光敏二极管 | |
IR-CUT | 支持 | |
IR Light | 2颗850nm红外灯 | |
白光灯 | 21颗大功率白光灯照射半径5M | |
WI-FI | 型号 | RTL8188FTV |
标准 | IEEE 802.11b/g/n | |
距离 | 10~20M(无阻隔) | |
扬声器 | 扬声器功能 | 支持 |
麦克风 | 灵敏度 | -36dB±2dB |
信噪比 | ≥58dB | |
存储方式 | 云存储 | 支持 |
TF卡存储 | 支持TF卡,最大128G | |
接口 | Reseti按钮 | 支持 |
电源接口 | USB 5V | |
电源适配器 | 输出 | DC5V2.5A |
认证 | CE.ROHS | |
配件 | 膨胀螺丝包 | 支持 |
保修卡、说明书 | 支持 | |
常规 | 工作温度 | -10℃-50℃ |
储存温度 | -20℃-60℃ | |
工作湿度 | 小于95%(无凝结) | |
其他要求 | 安装方式 | 上墙安装 |
包装清单 | 电源适配器×1摄像机×1说明书×1安装配件包×1 | |
白光灯 | 色温 | 6500-7000 |
显色数 | Ra79-81 | |
光通星 | 800-1000LM |
