E4A Bulb Camera
Product Overview：
1: 300W CMOS;
2: Full HD 2304*1296 resolution;
3: Fixed lens 4mm;
4: Support 2.4GHz & 5GHz WiFi & Bluetootch;
5: Dual light, 4 x 850nm IR light;
6: 12x white ambient lights;
7: Night vision distance up to 8-10M;
8: Support manual switching of ambient lights;
9: Supports motion and human detection;
10: Supports Siren and Private mode;
11: H.265 video compression technology;
12: Support DWDR, 3D noise reduction function;
13: Supports micro SD card slot, up to 256G;
14: Support cloud services(Subscribe);
15: Support phone remote monitoring (iOS, Android);
16: Support third-party value-added services, optional(Alexa、Google).
Subassembly | Parameters | Specification |
CPU | Specification | AK39AV130C |
Image sensor | CMOS size | 300W CMOS |
Effetive pixel | 2304H x 1296V(3MP) | |
Lens | Model | H0418 |
Focal length | 4mm | |
Relative aperture | F2.0 | |
Interface type | M12*P0.5 | |
FOV | 91° | |
WIFI | Model | ATBM6132C |
Standard | IEEE 802.11 b/g/n/ac 2.4GHz & 5GHz & BLE | |
Distance | 60-70m(No barriers) | |
PTZ | Angle | N/A |
Night Version | Photosensitivity mode | Sensor metering |
Colour temperature | 6500K White light | |
White light leds | 12PCS | |
Lumen | 1300lm | |
IR LEDs | 4pcs 850nm IR led | |
Distance | 10m | |
Switch mode | Smart full-color mode | |
Indicator light | Quantity | 1pcs white light |
SPK | SPK sensitivity | Support(1W,8Ω impedance,97±3dB) |
Microphone | Sensitivity | -36dB± 2dB |
SNR | ≥58dB | |
Storage mode | Cloud storage | Support |
Local storage | Up to 256G(SD cards are not included) | |
Interface | Micro SD card slot | Support(SD cards are not included) |
Reset button | Support | |
Power interface | E27 | |
Voltage | Compatibility | AC 110V~240V |
General | Working temperature | -10℃ ~ 50℃ |
Storage temperature | -20℃ ~ 60℃ | |
Working humidity | Less than 95%（Non-condensation） | |
Others | Installation mode | Hoisting |
Package list | Camera x1 User manual x1 |
